Radium Engineering Dual Catch Can Kit Nissan R32 Skyline GT-R Fluid Lock

The Radium Engineering Dual Catch Can Kit is a must-have upgrade for the Nissan R32 GT-R, specifically designed for the RB26DETT engine. This kit ensures optimal crankcase ventilation by addressing both the PCV (Positive Crankcase Ventilation) and CCV (Crankcase Ventilation) systems. By collecting oil and sludge before they re-enter the intake, the kit promotes cleaner air, improved engine performance, and enhanced durability.

Features:

• Dual Catch Can System – Includes both PCV and CCV catch cans to ensure comprehensive crankcase ventilation.
• Emissions and Track Legal – Fully sealed closed-loop system prevents venting to the atmosphere, promoting compliance with emissions regulations.
• Baffled Catch Cans with Dipsticks – Ensures efficient 2-step oil separation, with O-ring sealed dipsticks for easy fluid inspection.
• High-Quality Construction – Made with 10AN ORB ports, 4AN ORB drain ports, and stainless steel hardware designed for durability and reliability.
• RB26DETT-Specific Design – Tailored to the engine bay layout of the Nissan R32 GT-R for a perfect bolt-in installation.
• SAE Quick Connect Fittings – Lightweight and easy to install, making servicing straightforward and hassle-free.
• Protects Engine Performance – Reduces oil buildup in the intake system, helping to increase octane levels and maintain clean airflow.
• No Permanent Modifications Required – Easy install using factory mounting points; no cutting, drilling, or extra parts needed.

PCV Catch Can

• Mounts to the front RH strut tower using factory threaded bosses.
• Runs inline between valve cover crankcase vents and PCV valve.
• Prevents oil sludge, unspent fuel, and vapor from entering the intake manifold when under vacuum.
• Fully compatible with:
  • Factory engine bay-mounted battery.
  • OEM wastegate boost solenoid (relocation required).

CCV Catch Can

• Mounts to the windshield wiper motor on the LH side of the firewall.
• Runs inline between valve cover crankcase vents and turbo inlet pipe.
• Captures oil and sludge before they enter the intake, reducing oil buildup in the air filter, intercooler, and intake system.
• Compatible with factory ABS vehicles for seamless integration.

Specifications:

Why Choose the Radium Dual Catch Can Kit?

• Enhanced Engine Protection: Prevents blow-by contaminants from entering the intake system, which improves engine reliability during high-performance driving.
• Promotes Clean Airflow: Reduces oil buildup in sensitive parts like the intercooler, throttle body, and intake manifold, preventing performance degradation.
• Plug-and-Play Installation: Uses factory mounting points and includes all necessary hardware for a secure, bolt-in fit.
• Optimized for the RB26DETT: Includes valve cover press-fits and 10AN crossover hose to maintain the original intake and exhaust side balance as per Nissan’s design.
• Octane Boost: Cleaner inlet air directly improves octane levels for improved performance and efficiency.

What’s Included?

• 2 x Baffled Catch Cans with integrated O-ring dipsticks.
• Valve Cover Press-Fits specific to the RB26DETT engine.
• 10AN Adapter Fittings and Hose Ends.
• Pre-cut Radium 5/8" PCV Hose for easy installation.
• Nissan-Specific Mounting Brackets for PCV and CCV catch cans.
• Stainless Steel Hardware for secure mounting.

Additional Notes

1. Compatible with both factory ABS systems and engine bay-mounted batteries.
2. OEM wastegate boost solenoid may require relocation for proper functionality.

Upgrade your RB26DETT’s performance with the Radium Dual Catch Can Kit! Protect your engine, increase octane levels, and reduce harmful blow-by contaminants.

For installation support or technical inquiries, reach out to us directly.
